Backhoe loader SHHM ZL-388H - OVERVIEW

ZL-388H is the flagship model among Backhoe loadersof the special equipment Chinese manufacturer SHHM.

The total operating weight of the machine is 10,600 kg
Engine power - 75 kW
Bucket capacity - 1 m3
Backhoe capacity -0.3 m3

The unit is fully equipped for off-road operation: large equal-sized wheels, switchable front axle drive, three-mode steering.

The front loading equipment with parallelogram kinematics provides automatic leveling of the bucket during lifting and lowering.

The excavator equipment is mounted on a sliding carriage, which allows you to increase the digging radius from right to left without rearranging the machine and compactly fold the boom into the transport position. The telescopic stick provides a digging depth of up to 5 m.

The unit is driven by a 75 kW YUCHAI 4-cylinder engine connected to a mechanically operated hydraulic synchronized shift gearbox of SHHM's own design and production with 2 reduced and 2 increased gears.

The basic configuration of the model includes: tail lift, ROPS/ FOPS cabin protection system, air conditioning.

Especially for Russian operating conditions, the manufacturer installed an engine heating system on the machine, designed to facilitate starting the engine at low temperatures.

Upon customer request, the standard engine can be replaced with Cummins National II. Additionally, 6-in-1 and 4-in-1 buckets are offered; buckets wide 300 / 400 / 600 mm. If necessary, you can purchase a crusher or auger.

For questions about the purchase of this unit, please call 8 800 333 51 54.
